The innovative LokHead winch is a portable or fix-mounted load-lifting, personnel-hoisting winch used with an unlimited length of fiber rope. The captive head allows the winch to be used safely, and keeps the rope from accidentally releasing. Perfect for fixed or temporary applications and rescue. Harken Industrial offers the LokHead and its accessories fully boxed in a heavy-duty storage case that allows safe transport and rapid deployment.
The kit includes the LokHead winch with reversible plate, winch handle, universal tripod adapter, control lever, 2 carabiners, waterproof case and anchor strap with connectors to offer a variety of mounting options: clamped to tripods, rigged to ropes/strops, or anchored direct to structures.
Spare parts available from any Harken Industrial dealer. The simple construction requires no lubrication and can be flushed clean with fresh water.
Maximum line Ø (mm) 12.7 mm
Minimum line Ø (mm) 10 mm
Weight (kg) 13.6 kg
Weight of winch only (kg) 5.6 kg
Maximum working load for goods/equipment (kN) 4.9 kN
Maximum working load for goods/equipment (kg) 500 kg
Maximum working load for human suspension (kN) 2.4 kN
Maximum working load for human suspension (kg) 240 kg
Power ratio with 254 mm/10" winch handle 13.5:1/39.9:1
