The EZYiD-HT is a HDPE coated RFID tag designed to operate on most metallic and non-metallic surfaces. The primary characteristics of the EZYiD-HT tag include its performance when attached to metal, its size of 19mm x 10mm x 5.1mm moulded tag incorporating a 8.2mm slot for cable tie fitment and 3.5mm hole for screw fitment. The EZYiD-HT tag is available as a universal frequency operating between 865-956MHz.
The EZYiD-HT tag has been designed for special RFID applications like Industrial Asset tracking, tool tracking where the tag could be exposed to extreme environmental conditions.
Size: 19mm x 10mm
Mounting: Cable tie
RFID Protocol: EPC Class 1, Gen 2
Frequency: UHF 865-956 MHz worldwide
IC Type: NXP UCODE7
Memory: EPC 96bits
Data Retention: 50 years
Applicable Surfaces: For metal & non-metal surfaces
Read Range (on metal) with handheld reader: 10mm
Warranty: 1 year
